Learning SpringBoot + Temporal --- 01

---

Learning Spring Boot + Temporal to build Agent workflows: first write a small demo to verify environment connectivity

---

I. Learning Goals and Overall Environment

Learning Goals

• Run Temporal + Spring Boot end-to-end locally
• Understand Temporal’s basic model of Worker / Workflow / Activity
• Solve real networking and debugging issues in a WSL2 + Windows hybrid environment
• Obtain a reusable minimal runnable demo and troubleshooting experience

Actual Environment

• OS: Windows 11
• Subsystem: WSL2 (Arch Linux)
• Shell: fish
• Java: Java 25
• Build tool: Gradle (9.3.0)
• Temporal Server: running in WSL (CLI dev server)
• Spring Boot (3.5.10): running on the Windows host

---

II. Installing Temporal CLI (WSL2 / Arch)

1. Use the officially recommended installation method

Run in WSL (Arch):

curl -sSf https://temporal.download/cli.sh | bash

It will be installed by default to:

~/.temporalio/bin/temporal

2. Configure PATH (fish shell)

set -U fish_user_paths $HOME/.temporalio/bin $fish_user_paths

Verify:

temporal --version

If the version is printed correctly, the CLI installation is successful.

---

III. Starting the Temporal Dev Server (learning mode)

1. Start the server

temporal server start-dev

This command will:

• Start a local Temporal Server (Frontend / History / Matching combined)
• Listen on 127.0.0.1:7233 by default
• Automatically create the default namespace
• Be suitable for learning and local development (not production)

2. Verify server status

temporal operator cluster health

Output:

SERVING

This means the Temporal Server is providing services normally.

---

IV. Minimal Spring Boot + Temporal Worker Demo

1. Dependencies and technology selection

• Spring Boot: 3.5.10

• Gradle: 9.3.0

• Temporal Starter:

  implementation "io.temporal:temporal-spring-boot-starter:1.32.1"

2. Key configuration in application.yml

spring:
  application:
    name: demo

spring.temporal:
  namespace: default
  connection:
    target: 127.0.0.1:7233

  workers:
    - task-queue: greeting-task-queue
      workflow-classes:
        - org.ai.demo.GreetingWorkflowImpl
      activity-beans:
        - greetingActivityImpl

Key points:

• The configuration prefix must be spring.temporal (not temporal)
• The worker task-queue must exactly match the client’s configuration

---

V. Correct Way to Write Workflow / Activity (critical pitfall)

Wrong approach (application will fail to start)

// ❌ Calling in constructor or field initialization
Workflow.newActivityStub(...)

It will throw:

Called from non workflow or workflow callback thread

Correct approach (must follow)

@Override
public String greet(String name) {
    GreetingActivity activity =
        Workflow.newActivityStub(
            GreetingActivity.class,
            ActivityOptions.newBuilder()
                .setStartToCloseTimeout(Duration.ofSeconds(10))
                .build()
        );
    return activity.compose(name);
}

Core principle:

All Workflow.* APIs can only be called inside the Workflow execution thread. They must not be called during Spring Bean initialization.

---

VI. Triggering the Workflow via REST API (synchronous validation)

@PostMapping("/greet")
public String greet(@RequestParam String name) {
    GreetingWorkflow workflow =
        client.newWorkflowStub(
            GreetingWorkflow.class,
            WorkflowOptions.newBuilder()
                .setTaskQueue("greeting-task-queue")
                .build()
        );
    return workflow.greet(name);
}

Used to verify:

• Whether WorkflowClient is injected successfully
• Whether the Worker is polling the task queue
• Whether Workflow / Activity are actually executed

---

VII. Full Summary of WSL2 ↔ Windows Network Debugging

1. Problem symptoms

• Spring Boot listens on 0.0.0.0:8080 on Windows

• In WSL, run:

  curl http://localhost:8080

  Connection fails

2. Key understanding (very important)

• WSL2 is an independent virtual machine
• localhost in WSL ≠ localhost in Windows
• WSL → Windows must use the Windows host IP in the WSL NAT network

---

3. Wrong but common attempt

awk '/nameserver/ {print $2}' /etc/resolv.conf

The obtained IP (e.g., xx.xxx.xx.xx):

• Is not guaranteed to access Windows user-space services
• In this environment, the connection was refused

---

4. Correct and stable solution (fish shell)

Get the Windows host IP (recommended)

set WIN_HOST (ip route | awk '/default/ {print $3; exit}')

Example output:

172.25.112.1

Access Spring Boot via this IP

curl -v -X POST "http://$WIN_HOST:8080/api/greet?name=Alex"

Successful response:

HTTP/1.1 200
Hello Alex @2026-01-27T09:20:39.294459200Z

---

VIII. Facts Confirmed from the Successful Result

From this single successful curl response, we can confirm all of the following:

1. WSL → Windows network link is working
2. Spring Boot service is externally accessible
3. The Controller works correctly
4. WorkflowClient has successfully connected to the Temporal Server
5. The Worker is polling the task queue
6. The full flow of Workflow → Activity → result return is working

This is a real Temporal Workflow execution, not a fake success.

---

IX. Complete Call Chain Review (one successful request)

WSL curl
  ↓
Windows Spring Boot (/api/greet)
  ↓
WorkflowClient
  ↓
Temporal Server (WSL, 7233)
  ↓
Worker polls task queue
  ↓
Workflow execution
  ↓
Activity execution
  ↓
Result returned

---

X. Recommended Daily Development Habits (WSL2 + fish)

# Get Windows host IP (most reliable)
set WIN_HOST (ip route | awk '/default/ {print $3; exit}')

# Call the service running on Windows
curl http://$WIN_HOST:8080

Avoid relying on:

• localhost
• the nameserver in /etc/resolv.conf
• PowerShell’s curl alias
